Accessories for Vers. Industrial 800
These and many others
V/4C
Dosatrice a 4 coclee
V/4F
Dosatrice a 4 coclee
V/6F
Dosatrice a 6 coclee
TS/0
Tappeto superiore orientabile
UDR/2R
Umidificatore a dischi rotanti con distributore di zucchero o semi
TCA-I
Gruppo calibratore indipendente
TRR/E
Tappeto recupero ritagli
A-90E
Impadellamento retrattile
Technical data
DIMENSIONI
| Conveyor belt width | 650 mm |
| Available conveyor belt length | 5500 mm 6500 mm 7500 mm 8500 mm |
| Belt speed | 0-8 mt./min. |
TAGLIO
| Useful width | 580 mm |
| Min. cutting length | 10 mm |
| Number of strokes | 120/min. |
MATRICE
| Max. die length | 200 mm (single) 350 mm (double) |
| Max. die width | 580 mm |
| Max. number of strokes | 80/min. |
| Max. dough thickness | 15 mm |
DOSATRICE
| Hopper capacity | 50 lt. |
| Deposit mode | spot intermittent continuous |
| Quantity of filling per outlet | spot 5-60 gr. |
Some examples of finished products
These and many others
